tread aluminum sheet plate-全讯新
description by manufacturer
specifications of tread aluminum sheet :
1. aluminum sheet and plate & panel.
2. thickness: 0.05-3.0mm
3. width: 16 - 1250mm
4. surface: be free from oil stain, dent, inclusion, scratches, stain, oxide dicoloration, breaks, corrosion, roll marks, dirt streaks and other
5. standards: gb/t 3880-2006, q/q 141-2004, astm, jis, en
parameters of aluminum sheet :
| division | description | application | feature |
| 1000 series | 1050, 1060, 1070, 1100, 1200, 1235 | utensil, solar panel, decoration, reflecting plate, printing plate, heatproof plate, cookware. | easy to process and weld, resistant to rust, high, conductibility of electricity and heat, low strength |
| ho, h12, h14, h16, h18, h22, h24, h26,h32, h34, h321, h116, h111 etc. | |||
| 1xxx series is also known as pure aluminum. purity can achieve 99.00% above. | |||
| 3000 series | 3003, 3004, 3005, 3105, 3a21 | utensil, aluminum can, building, chemical equipment, cellular phone, air conditioning, refrigerator. | 20% higher strength than the 1100 series, easily welded and brazed, good anti-rust, ability non-heat treatable |
| ho, h12, h14, h16, h18, h22, h24, h26, h32, h34, h321, h116, h111 etc. | |||
| the 3xxx series aluminum plate is by manganese as the main component. content is between1.0 and 1.5. it has a good rust-proof function. | |||
| 5000 series | 5005, 5052, 5083, 5754, 5086, 5182 | ship board heatproof apparatus, building, parts of electronic tools. automobile components | low density, high tensile strength, elongation rate is high. in the same area, weight is less than other series. |
| h22, h24, h26, h32, h34, h321, h116, h111 etc. | |||
| main element is magnesium, in the amount between 3-5%. | |||
| 6000 series | 6061, 6101, 6082, 6063 | it equipment & facility, hinge head, brake piston, | easy to process , good corrosion resistance, high toughness and processed without distortion after heat-treatable, superior surface treatment |
| t5, t6 | |||
| it mainly contains magnesium and silicon, applies to be against corrosion, oxidizing demanding applications. | |||
8000 series | 8011, 8079, 8006, 8090, 8093 | packaging, household, air conditioner, decoration, bottle cap. | clean, non-toxic proof, odorless and tasteless, light proof, good malleability etc. |
